Neutral Salt Spray Test Chamber GT-F50BA
Neutral Salt Spray Test Chamber GT-F50BA Product Introduction Application: Salt spray tester: It aims at determining the product corrosion resistance after various kinds of materials surface suffering electroplating, anodizing, painting, rust-proof oil corrosion resistance treatment. Salt Spray Test Chamber is suitable for neutral salt spray test (NSS). Standards: CNS3627, 3885, 7669, 8886, JIS D-0201, H-8502, K-5400, Z-2371, ISO 3768, EN 248 ASTM B-117, B-268, GB-T2423 DIN 50021-SS Feature: The whole Salt Spray Machine adopts material of 5mm import gray PVC sheet, Internal adopts advanced band produced three-dimensional reinforcement technology, with strong structure, no deformation, acid and alkali resistance, high temperature resistance, and no aging. It is applied to all kinds of test specifications such as salt spray, copper acetate, etc. Heating method: test room adopts steam direct heating method, temperature rise fast and uniform, reduce the standby time, the heating tube is made from titanium tube with high corrosion resistance. Hopper: 2 built-in spray quantity collection cylinder (only one 60 type ), comparing to the traditional external type, it does not easily break down. Laboratory commodity shelf uses plane dividing shelf, commodity shelf is the ¢10mm toughened glass rod with corrosion resistance. Plastic steel V type shelf and glass rod placing objects make sure the sample 30 degree bevel angle, the angle can be arbitrarily adjusted,the direction of spray falling around is the same as the direction of spay receiving, test piece is set with large quantity. Salt Spray Cabinet body support: SECC U-bar with angle iron spray paint, four wheel slide and can be pushed for moving( limit use for 120 L type or more than 120 L). Pressure barrel: 2.0MMSUS201 stainless steel seamless welding. Heating delivery: titanium tube used, long service life, high degree corrosion resistance. Salt Spray Test Equipment cover: made of 5MM import transparent acrylic sheets, exquisite workmanship, beautiful appearance. Dual function of over-temperature protection attached, when over-temperature the warning display and cut off the heater power to make sure safe use. Including automatic spray exhausting device. Can clear observe the sample in the test room. Sample supplement jar adopts hidden and water level perspective window attached, it is easy to clean and not easy cracking. salt spray chamber specification Model GT-F50BA-1 GT-F50BA-2 GT-F50BA-3 GT-F50BA-4 GT-F50BA-5 Inside Chamber Dimension (WxDxH cm) 60x45x40 90x60x50 120x100x50 160x100x50 200x120x60 Outside Chamber Dimension (WxDxH cm) 107x60x118 141x88x128 190x130x140 230x140x140 270x150x150 Test Chamber Volume 108L 270L 600L 800L 1440L Brine Tank 15L 25L 40L 40L 40L Control Method Touch Screen Plastic Plate Thickness 5mm Temperature of Test Chamber Brine test method 35℃±1℃ Temperature of Pressure Barrel Brine test method 47℃±1℃ Brine Temperature 35℃~ 50℃ Brine Concentration 5% sodium chloride solution concentration Compressed Air Pressure 1.00±0.01kgf/cm2 Spray Volume 1.0~2.0ml/80cm2/h(gather at least 16 hours, take its average) Relative Temperature of Test Chamber Above 85% PH-value Neutral: 6.5~7.2 Spray Method continuous spray or intermittent spray Power Supply AC220V1Φ10A AC220V1Φ15A AC220V1Φ30A Temperature Range Laboratory temp. 35℃- 50℃(can be arbitrarily set) Pressure barrel temp. 47℃- 63℃(can be arbitrarily set) Temperature Rising Speed Laboratory Room temperature →35℃ about 35 minutes Pressure barrel Room temperature →47℃ about 15 minutes Temp. accuracy ±1℃
