Model

GT-N22

Sample Size

38×80mm (Standard)

Actual measured size

38×50mm (Standard)

Span range

1~60mm, 5mm, 10mm, 15mm, 20mm, 25mm, 30mm, 40mm, 50mm

8 grates for adjustment.

Span accuracy

±0.1mm

Testing Range

(0~10000)mN

Sensor accuracy

±0.1%

Resolution

0.01mN

Bending Angle

Adjustable between 1 to 92º

Angle Accuracy

±0.1º

Angle measure

A single test can measure 3 different angles at the same time

1-90º can be set arbitrarily

Angular speed Control

0.5 – 50 °/sec
Three test angles and duration are independently adjustable

Testing Thickness

0.01~5.0mm

Bending Time

Adjustable according to different material

Sample grip

Manual clamp, automatic reset after test

Clamping mode

Unlimited holding, can be non-destructive continuous clamping

Printer

Thermal Printer

Data Display

7inch Touch Screen Display, Visual menu operation.

Calibration

Self-calibration, equip calibration tools
