Brand:
GESTERItem NO.:
GT-N14Order(MOQ):
1Payment:
T/T, L/CLead Time：
15-30 daysProduct Detail
Application:
This machine is to test the compressive strength properties of materials testing instruments, mainly applicable to all types of less than 300mm diameter paper industry tube, chemical fiber paper tube, packet carton and other types of small containers or honeycomb compressive strength, deformation detection, but also can be tube paper board RCT, ECT, FCT, PAT and CMT.
It references ISO standards and the newest national standards for paper tube, Structure for the mechanical-electrical integration, the introduction of modern mechanical design concepts and computer technology to carefully handle a reasonable design.
Paper tube compression tester used on the fixed platen, high measurement accuracy. A powerful data-processing functions, the data can be directly obtained results with the pressure curve display.
Standards:
ISO 11093-9, BB/T 0032
Feature
High speed return after finishing test.
The test result can be measured, statistical and printed automatically and the data can be saved.
Touch screen control and display, which can be display the crush time and loading force real time, displaying crush graph real time.
Thermal printer, high speed and no noise .
Tube Crush Tester use the modern design idea of mechanical and electrical integration, which has compact configuration, pleasing appearance and convenient maintenance.
|
Models |
GT-N14A |
GT-N14B |
|
Plate Size |
200 x 300 mm |
300 x 300 mm |
|
MAX stroke |
200 mm |
300 mm |
|
Measuring Range |
0-5000N |
|
|
Compression Speed |
0-60mm/min (Can be adjusted digitally)） |
|
|
Display |
Touch screen |
|
|
Printer |
Thermal printing, high speed and no noise |
|
|
Power Supply |
1Φ 220V 50/60Hz |
|
|
Dimension |
About 700 × 500 × 1100mm (L × W × H) |
|
|
Weight |
About 120kgs |
|
