Needle Detector GT-MC44-1

needle detector machine
  • Brand:

    GESTER
  • Item NO.:

    GT-MC44-1
  • Order(MOQ):

    1
  • Payment:

    TT or L/C
  • Shipping Port:

    Xiamen Port
  • Lead Time:

    10 days
  • Product Detail

Needle Detector GT-MC44-1


Product Introduction


Application:

Needle Detector is the digital high anti-interference performance and high sensitivity detector. It is for detecting needle, iron balls and other magnetic metal in the textile products. It can remove effectively the interference with electromagnetic waves in the Ceiling fans, sewing machine and sealing machine.


Detecting Broken Needle: Women' dress, men' clothing, work clothes, baby products, knitwear, underwear, socks, fabrics, non-woven fabrics, embroidery, towels, bath towels, carpets, gloves, toys, handicrafts and all textile products.

Check the needle: metal buttons, metal zipper, the word deduction, beads, brooches and other clothing handbags metal accessories.

Aluminum foil packaging: suitable for checking metal in the food with aluminum foil packaging.


Feature
  • Full steel frame with painting body. Compared to the traditional aluminum, strong steel frame, more beautiful flaps, and stronger anti-collision and anti-weak magnetic resonance interference, suitable for jointing the line operations.
  • The probe height can be made in a variety of combinations, and various specifications can be selected to increase or reduce the probe height to adapt to a variety of needle height and sensitivity.
  • Japanese movement, imported photoelectric sensor, imported food-grade non-toxic conveyor belt for needle detector, with universal casters, easy to move.
  • Super anti-interference computer chip integrated circuit, dual-channel pin array sensor, better than the traditional dual-probe needle detector.
  • All function keys are light-touch membrane switches, which avoids the shortcomings of mechanical buttons that are easy to damage.
  • With position display function, the exact needle break position function is displayed at eight o'clock (optional printer function module)
  • With counting function, distinguish between good and bad products (genuine, defective, total).
  • The alarm function is three kinds of sound, light and frequency display, and the sensitivity is 10~100 levels of decimal adjustment.
  • Special protection circuit, 10 minutes without the test object through the automatic shutdown (workable in automatic mode, not in manual mode.
  • It includes B / C (accessories / finished) mode switching function, to adapt to different detection of products.
  • When a broken needle or an iron object is detected, there are two alarm modes of sound and light, and the machine stops and falls back to the starting point, and runs automatically again.


Key Specifications


Model

GT-MC44-1

Number of detection head

1

Detection width

600mm

Detection ability

Select one

≥Φ0.8

≥Φ1.0

≥Φ1.1

≥Φ1.2

≥Φ2.0

Detection height



100mm

130mm

150mm

180mm

220mm

Detection method

magnetic field induction, computer detection

Detection adjustment

1-12 grade(adjustable)

Power Supply

220V 50-60Hz

Power

120W

Weight

250KG

Dimensions

1600×1000×910/930/980/1100(mm)
