Low Temperature Flexing Test Chamber GT-KC04C

For Bally Flexing Resistance Test

SATRA TM 55; IULTCS/IUP 20-1;

ISO 17694 ; EN 13512 ;

EN344-1 section 5.13.1.3 and annex C;

GB/T20991 section 6.6.2.8;

AS/NZS 2210.2 section 6.6.2.8;

JIS-K6545; BS 3144 clause 13

Equipped with A type of upper grips.

ISO 32100 ; DIN53351; ISO5402-1;

GE-24; ASTM D 6182;

EN ISO 20344-2021 section 6.6.3

Equipped with B type of upper grips.

For ROSS Flexing Test

ISO 5423 section 5.2, EN ISO 20344 Section 6.5, ISO 4643 (Annex B), AS/NZS 2210.2 Section 6.5.2

SATRA TM25, EN ISO 22288, ISO 5402-2, GB/T 20991 Section 6.5.2, GB20265 section 6.11, QB/T 2224, ISO4643

Model

GT-KC04C

Flexing Parameters

Types of Test Grips

Upper and Vamp Flexing test grips (40degree V-shaped)

Bally flexing test grips

Number of Position

12pcs

5pcs

Flexing Speed

90±9CPM

100±5 CPM

Bending Angle

/

22.5°

Control System

Touch Screen Programmable Microprocessor Control

Temperature range

-40~100℃

Inside Chamber capacity

150L

Power Supply

1∮AC220V 50/60HZ

Weight

About 420kg
