Glow Wire Test Apparatus (LCD Display) GT-MC35H-1 Glow Wire Test Apparatus (LCD Display) GT-MC35H-1 Glow Wire Test Apparatus (LCD Display) GT-MC35H-1 Glow Wire Test Apparatus (LCD Display) GT-MC35H-1 Glow Wire Test Apparatus (LCD Display) GT-MC35H-1
Glow Wire Test Apparatus (LCD Display) GT-MC35H-1
  • Brand:

    GESTER
  • Item No.:

    GT-MC35H-1
  • Certificate:

    ISO 9001, UKAS, CE
  • Standard:

    IEC60695 GB5169
  • Shipping Port:

    Xiamen Port
  • Lead Time:

    30 days
  • Payment:

    T/T, L/C
contact now Download

Glow Wire Test Apparatus (LCD Display) GT-MC35H-1

Product Introduction of glow wire test apparatus


Application

Glow wire tester is the latest release of the flaming test equipment, with imports of touch-screen controller and instrument.

New test circuit, stable performance, reliable, simple and easy to operate. wide range of parameter adjustment. The Glow Wire Tester is apply to the latest test standards IEC60695,GB5169, etc.


Glow wire test Standards:

IEC60695 ; GB5169


Dimensions of glow wire test apparatus


Glow Wire Tester



Feature of glow wire test apparatus



1. Glow Wire Tester Digital indicator control system.

2. Full import control components.

3. Special high-quality stainless steel clamps.

4. Wireless remote control timing device.

5. Advanced temperature control ang measuremtnt system.


GT-MC35H glow wire test apparatus


Key Specifications of glow wire test apparatus


Outside dimension

1120×600×1020mm ( L×W×H)

Glow wire

Φ4mm Ni/Cr(80/20)

Thermocouple

Φ1mm K type

Glow temperature

150degree~1000 degree (adjustable)

Sample pressure

1.0N±0.1N

Sample move speed

10mm /s~25mm /s(adjustable)

Apply temperature time

0.01s99.99s(adjustable)

Start burning time

0.01s~59m59.99s

Continue burning time

0.01s~59m59.99s

Power supply

Single-phase AC 220 V 50/60Hz





Application Industry of glow wire test apparatus

All kinds of below products and materials can be tested on the Glow Wire Tester GT-MC35H

GT-MC35H glow wire test apparatus
