Shoe Slip Resistance Tester GT-KB48

Slip Resistance Tester is to measure the sole friction coefficient, and then judge the slip resistance of shoes.
  • Brand:

    GESTER
  • Item NO.:

    GT-KB48
  • Order(MOQ):

    1
  • Payment:

    T/T, L/C
  • Shipping Port:

    Xiamen Port
  • Lead Time:

    10-30 days
  • Product Detail

Slip Resistance Testing for Footwear GT-KB48



Product Introduction


Application:

Slip Resistance TesterApply a predetermined load by different mediums like wood, PVC, ceramic tile or specified and set specified friction times and speed, which is to measure the sole friction coefficient, and then judge the slip resistance of shoes.


Standards:
ISO 13287, GB/T 28287, ASTM F2913, SATRA TM 144,  ISO 24267, ISO 20344,

JIS T8101, JIS T8106, JIS T8107


Dimensions

SATRA TM144 Slip Resistance Tester GT-KB48


Shoe Slip Resistance Tester Principle

Place specimen on test stand, and glycerin as a lubricant, exert a certain load, and move test bench in horizontal direction compared with sample by lateral traction forces, to measure dynamic friction and calculate kinetic coefficient of friction.


Key Specifications


Model

GT-KB48

Vertical load cell range

1000N

Horizontal load cell range

1000N

Sliding speed

(0.3±0.03)m/s

Static contact time

0.5s

Test normal force

500±25N, For footwear of European size 40 (UK size 6.5) and above

400±20N, For footwear of European size below 40 (UK size 6.5)

Wedge angle gauge

Control method

Computer-controlled

Monitor

19-inch

Test floor

Pressed ceramic tile floor, stainless steel plate

Power supply

AC 220V 50/60HZ

Dimensions

180×90×130 cm

Weight

240 kg

Standards

ISO 13287, GB/T 28287, ASTM F2913, SATRA TM 144,  ISO 24267



Standards accessories

2pcs

7°Wedge angle gauge

2pcs

Shoe last fixture

2pcs

Prosthetic foot fixture

1pc

180×90×90mm calibration rubber fixture

1pc

Stainless steel plate

1pc

100×70mm steel block

1pc

Power line

Optional accessories

Optional

SATRA Pressed ceramic tile floor
