Textile Ultraviolet Prevention Performance Tester

Textile Ultraviolet Prevention Performance Tester

Textile Ultraviolet Prevention Performance Testing Machine GT-C30

fabric testing machine manufacturer | UV penetration & protection test system

Brand:
GESTER
Item NO.:
GT-C30
Order(MOQ):
1

Inquire now

Product Detail

Textile Ultraviolet Prevention Performance Testing Machine GT-C30

Product Introduction

Application:

Used to evaluate the performance of fabrics in protecting against solar ultraviolet radiation under specified conditions.

Standards:

GB/T 18830, AATCC 183, BS 7914, EN 13758, AS/NZS 4399, JIS L 1925

Principle

Utilizes a xenon arc lamp as the light source and optical coupling optical fiber for data transmission.
Fully computer-controlled with automatic data processing and storage.
Various graphics and report statistics and analysis.
The application software includes pre-programmed solar spectral radiation factors and CIE spectral erythema response factors, which can accurately calculate the UPF value of the sample.
The constants ta/2 and n-1 are open to users, who can input values by themselves to participate in the calculation of the final UPF value.

Key Specifications

Model	GT-C30
Detection wavelength range	(280～410) nm, resolution: 0.2nm, accuracy: 1nm
T(UVA) (315nm～400nm)testing range	(0～100)%, resolution: 0.01%, accuracy: 1%
T(UVB) (280nm～315nm)testing range	(0～100)%, resolution: 0.01%, accuracy: 1%
UPFi testing range	0～2000, resolution: 0.001, accuracy: 2%
UPF (Ultraviolet Protection Factor) range	0～2000, accuracy 2%
Test results	T(UVA)_AV_, T(UVB)_AV, UPF_AV_,UPF value
Power supply	AC220V 50Hz 100W
Weight	Approx. 40kg

Accessories

Standard accessories	1set	Host machine
	1set	Computer
	1set	Printer
	1set	Software
	1pc	USB communication cable
