GESTER Paper Packaging Testing Instruments is designed in accordance with TAPPI, ISO, ISTA, ect standards, which is widely used in paper and package industries (such as corrugated fiberboard, flexible packaging, lamination, adhesives etc).
Cardboard Stiffness Tester GT-N40 Product Introduction Application: Cardboard stiffness is the test of cardboard bending strength, the use of TABER (TABER) type stiffness tester. Suitable for determining the stiffness of paper and cardboard of low weight and thickness less than 1mm, the cardboard stiffness tester is the international standard common Taber (Taber) type stiffness tester. The instrument is suitable for paper and cardboard bending strength indicators, is the determination of cardboard stiffness of the special instrument. Standards: ISO 5628, ISO 2493-2, GB2679.3, QB/T 1051, GB/T 22364, TAPPI T489 Principle Designed according to the principle of equilibrium of the moment against the center of the rotating axis. The moment required for a piece of specimen, which is clamped vertically to the free end of the specimen, to be bent at an angle of 15° under the set conditions is the degree of the specimen, in units of MN, M. Feature The instrument adopts bilateral measurement and calculates the average value for more accurate data. Equipped with precision bearings to reduce friction. Mechanical structure, economical and practical. Key Specifications Model GT-N40 Measuring range (1-500)mN.m(divided into 7 ranges) Display error ±2% (10% to 90% of the upper limit value for each grade) Variability ≤2% (10% to 90% range of the upper limit of measurement for each grade) Pendulum arm length 100mm Load force arm length 50mm±0.1mm Test speed 200°±20°/min Rated bending angle 7.5°±0.3° and 15°±0.3° Sample size 70mm×38mm (L×W) Environmental Conditions Temperature 20–40℃, Relative Humidity ≤85% External dimension 240 ×230×350 mm (L×W×H) Weight About 15.5kg
Puncture Resistance Tester is for various kinds of cardboard such as boxboard an Corrugated cardboard. The tester is designed according to the standard.
Corrugating Medium Flute Tester is used to test the flat compression and vertical compression strength of corrugating medium after laboratory fluting corrugating medium.
Automatic Bursting Strength Tester GT-N29D is available to test a variety of paper. It also can be used for non-paper sheet materials' bursting, such as silk and cotton.
This Schopper Air Permeability Tester was designed according to QB/T1667. It is used to test the air permeability of materials like paper, bag of cement, cable paper and so on.
Large Packaging Drop Testing Equipment GT-LC09 Product Introduction Large Packaging Drop Tester with dual motor control and two beams, labeled as "A" and "B." This advanced testing device offers comprehensive evaluation of package impact strength, including surface, angle, and edge assessments. Notably, it has overcome the challenges of fixed-angle drop testing found in traditional methods. This Drop Tester adding three protective functions to ensure operator safety. The landing gear operates only when all three safety features are activated, effectively minimizing the risks of accidents and safeguarding personnel. Whether you represent a large corporation or a small-to-medium enterprise, our Large Packaging Drop Testing Equipment meets the strict demands for packaging quality. By saving time and costs, it enhances product reliability and customer satisfaction. Key Specifications Model GT-LC09 Max.weight of sample 800kg Control mode PLC+Touch screen Motor 0.75 variable frequency motor + frequency changer (2groups, for adjusting height of "A" and "B" beams separately.) Moving Range 0~1200mm (adjustable) Air Cylinder Protective cylinder(4pcs) + Protective and power cylinder(4pcs) Accelerating structure 4 groups (The speed of landing gear must be higher than drop speed of sample) Anti-friction Bearing NSK Weight 3000kg Dimension 2800×2500×2500mm(L×W×H) Standard ISTA
Smoothness Tester based on Buick BEKK principle and compliant with ISO 5627/GB/T 456. Its touch-screen control and three test levels (I–III) simplify smoothness testing for paper/board. Fully automated, it ensures consistent results with minimal maintenance. Safety features like pressure relief and quiet operation (<50 dB) enhance usability. Ideal for paper mills and R&D labs, it’s a durable, future-ready solution for quality control.
