Altitude Simulation Test Chamber GT-I18 Product Introduction Application: This test case is designed for UL, EN, IEC and other standard testing requirements. It can reach the low-pressure storage state of the sample in a short period of time, automatically control the test cycle, monitor the pressure changes inside the box throughout the process, and achieve automatic termination of the test. Simulate the storage of batteries and battery packs for 6 hours under conditions of pressure equal to or lower than 11.6kPa and ambient temperature of (20 ± 5) ℃. The batteries are considered qualified if they do not explode or ignite. Standards: GB/T 31485, GB/T 31241, UN38.3, IEC62133, UL 1642 Using Environment Requirement Environmental temperature: 0-50 ℃. Relative humidity: 45-85% RH. Atmospheric pressure: 86-106KPa. No direct sunlight or direct radiation from other heat sources. There is no strong vibration around. High-Altitude Simulation Chamber Key Specifications Model GT-I18 Inner box material SUS304 stainless steel plate, thickness 5.0mm Pressure range 5～100KPa Pressure Accuracy 0.1KPa Inner box dimensions 800x800x800mm Viewing windor The size is 300x350mm with two layers of tempered glass, and the transparent window is equipped with stainless steel mesh. Control mode Touch screen control Vacuum Time Free setting within 0-99H99 Pressure fluctuation ≤5%
Large Packaging Drop Testing Equipment GT-LC09 Product Introduction Large Packaging Drop Tester with dual motor control and two beams, labeled as "A" and "B." This advanced testing device offers comprehensive evaluation of package impact strength, including surface, angle, and edge assessments. Notably, it has overcome the challenges of fixed-angle drop testing found in traditional methods. This Drop Tester adding three protective functions to ensure operator safety. The landing gear operates only when all three safety features are activated, effectively minimizing the risks of accidents and safeguarding personnel. Whether you represent a large corporation or a small-to-medium enterprise, our Large Packaging Drop Testing Equipment meets the strict demands for packaging quality. By saving time and costs, it enhances product reliability and customer satisfaction. Key Specifications Model GT-LC09 Max.weight of sample 800kg Control mode PLC+Touch screen Motor 0.75 variable frequency motor + frequency changer (2groups, for adjusting height of "A" and "B" beams separately.) Moving Range 0~1200mm (adjustable) Air Cylinder Protective cylinder(4pcs) + Protective and power cylinder(4pcs) Accelerating structure 4 groups (The speed of landing gear must be higher than drop speed of sample) Anti-friction Bearing NSK Weight 3000kg Dimension 2800×2500×2500mm(L×W×H) Standard ISTA
Electric Pencil Hardness Tester GT-H100 Product Introduction Application: This machine is used to test film hardness through plow-breaking paint film. Hardness will be showed via pencil mark of plow-breaking paint film under specified testing condition. Standards GB/T6739-1996,JIS K5401, ASTM D2197 Key Specifications Model GT-H100 Test angle 45 degree Load 500g, 250g, 250g Balancing weights 500g Moving speed of test bench 5mm/s (adjustable) Travel distance 90mm Test bench Approx.12x17cm, can fix the sample Power supply 1 phase 220V / 50Hz Accessories Pencils (6B~ 6H) 1set, Load 1set
Smoothness Tester based on Buick BEKK principle and compliant with ISO 5627/GB/T 456. Its touch-screen control and three test levels (I–III) simplify smoothness testing for paper/board. Fully automated, it ensures consistent results with minimal maintenance. Safety features like pressure relief and quiet operation (<50 dB) enhance usability. Ideal for paper mills and R&D labs, it’s a durable, future-ready solution for quality control.
This Footwear Testing Machine to determine right angle flexing resistance at low temperature for whole sole of rubber, PU, PVC, TPR foam and other materials.
