Brand:
GESTERItem NO.:
GT-I02Order(MOQ):
1Lead Time：
15-30 DaysProduct Detail
Application:
This test case is designed for UL, EN, IEC and other standard testing requirements. It can reach the low-pressure storage state of the sample in a short period of time, automatically control the test cycle, monitor the pressure changes inside the box throughout the process, and achieve automatic termination of the test. Simulate the storage of batteries and battery packs for 6 hours under conditions of pressure equal to or lower than 11.6kPa and ambient temperature of (20 ± 5) ℃. The batteries are considered qualified if they do not explode or ignite.
Standards:
GB/T 31485, GB/T 31241, UN38.3, IEC62133, UL 1642
|
Model |
GT-I18 |
|
Inner box material |
SUS304 stainless steel plate, thickness 5.0mm |
|
Pressure range |
5～100KPa |
|
Pressure Accuracy |
0.1KPa |
|
Inner box dimensions |
800x800x800mm |
|
Viewing windor |
The size is 300x350mm with two layers of tempered glass, and the transparent window is equipped with stainless steel mesh. |
|
Control mode |
Touch screen control |
|
Vacuum Time |
Free setting within 0-99H99 |
|
Pressure fluctuation |
≤5% |
